Payment Method Name
Set payments[].paymentInstrument.paymentMethodName to ByBitPay when creating an Intent: "paymentMethodName": "ByBitPay"

📘
Bybit Pay lets your customers pay by scanning a QR code with Bybit. In the H2H flow, you create an Intent with a Payment, receive the QR image in the synchronous response, and display it on your checkout page. The payer scans the QR, reviews the transaction details, and confirms the payment in Bybit. Configure a webhook URL in the request or in your settlement account settings to receive status updates.

Payment Method Features

Payment Method	VietQR
Country	--
Processing Currencies	USDT
Payments	Yes
Disbursements	Yes
Refunds	Yes
Chargebacks	No

Workflow: Payment

📘
In step 1.7, display the QR from payments[].additionalData.details.qrBase64 on your checkout page.
incomingDetails.redirectUrl and incomingDetails.failureUrl are the payer's return destinations after the payment attempt. Payment status notifications use the webhook URL configured for the payment or its settlement account.

Possible Payment Scenarios

Scenario	Steps
QR creation	[1.1] The payer chooses Bybit Pay on your checkout page. [1.2] You send `POST /processing/api/v1/intents` with a Bybit Pay payment. [1.3] Our platform creates the `Intent` and `Payment`. [1.4–1.5] Our platform creates the Bybit order and obtains its QR. [1.6] The synchronous response contains the created objects, payment status, and QR image. [1.7] You display the QR to the payer. The payment awaits confirmation in `AUTHORIZATION_REQUESTED`.
Successful payment	[2.1] The payer scans the QR in Bybit. [2.2–2.4] Bybit displays the transaction details, the payer confirms the payment, and Bybit displays the result. [2.5–2.6] Our platform receives the successful payment result and changes the payment status to `CAPTURED`. [2.7] Our platform sends a webhook to the configured URL.
QR expiration	[3.1] The payment session expires before the payer completes the payment. [3.2] Our platform changes the payment status to `CANCELLED`. [3.3] Our platform sends a webhook to the configured URL with the updated status.

📘
Use the payment status received from our platform to confirm the result. Returning the payer to redirectUrl or failureUrl is part of the browser flow and does not replace a payment status notification.
Stop displaying the QR when the payment session expires or the payment reaches a final status. If a result notification is unavailable, retrieve the current payment status.

List of Used API Requests

Request	Endpoint	Description
Intent creation	`POST /processing/api/v1/intents`	Creates an `Intent` with a Bybit Pay `Payment` and returns the QR when creation succeeds.
Refund creation	`POST /processing/api/v1/refunds`	Creates a refund for an existing payment in `CAPTURED` status.
Payment status	`GET /processing/api/v1/payments/{id}`	Retrieves the payment and its current status. Use the platform payment ID.
Refund status	`GET /processing/api/v1/refunds/{id}`	Retrieves the refund and its current status. Use the platform refund ID.

Use the standard platform authentication and settlement-account-id header described in the API reference. The examples below show JSON request and response bodies.

Intent Creation Request/Response

📓
Request specifics

Endpoint: POST /processing/api/v1/intents.

Payment method: ByBitPay.

Method-specific data: payments[].paymentInstrument.incomingDetails.

Required incoming details: redirectUrl, failureUrl, terminalType, device, browserVersion, and ip.

Optional incoming detail: sessionTimeoutMin.

Intent Request: Template

CURRENCY_CODE is a placeholder: replace it with the currency enabled for your integration. This example uses the same submitted and authorisation currency. The sample amount is illustrative.

{
  "clientReferenceId": "order-bybit-1001",
  "useCheckoutForm": false,
  "payments": [
    {
      "paymentInstrument": {
        "paymentMethodName": "ByBitPay",
        "incomingDetails": {
          "sessionTimeoutMin": 20,
          "redirectUrl": "https://merchant.example.com/payments/success",
          "failureUrl": "https://merchant.example.com/payments/failure",
          "terminalType": "WEB",
          "device": "checkout-device-01",
          "browserVersion": "Chrome/133.0.0.0",
          "ip": "203.0.113.10"
        }
      },
      "submittedAmount": {
        "value": 100.50,
        "currency": "USDT"
      },
      "authCurrencyCode": "USDT",
      "webhookUrl": "https://merchant.example.com/webhooks/payments"
    }
  ]
}

Intent Request: Fields Description

Top-Level Request Parameters

Parameter	Type	Required	Description
`clientReferenceId`	String	Required	Your reference for the intent, such as an order number.
`payments`	Array of Objects	Required	Payments to create within the intent. Include the Bybit Pay payment in this array.
`useCheckoutForm`	Boolean	Optional	Set to `false` for this H2H flow. Defaults to `false`.
`description`	String	Optional	Intent description. In the sandbox, use this top-level field to select an emulator scenario. See Testing in Sandbox.

payment — payments[]

Parameter	Type	Required	Description
`paymentInstrument`	Object	Required	Payment method and its incoming details.
`submittedAmount`	Object	Required	Payment amount and currency submitted to the platform.
`authCurrencyCode`	String	Required	Currency used to authorise the payment. Use a currency enabled for your integration. If no currency conversion is needed, use the same value as `submittedAmount.currency`.
`webhookUrl`	String	Optional	HTTPS endpoint for this payment's status updates. Overrides the settlement account's default webhook URL. If omitted, the account default is used. Configure either URL to receive notifications.
`payer`	Object	Optional	Payer details, if supplied. See the common Intent API reference for the object schema.
`description`	String	Optional	Description of this payment. The sandbox scenario keyword belongs in the top-level intent `description`.
`billingAddress`	Object	Optional	Payer billing address, using the common API schema.
`totalTaxAmount`	Object	Optional	Tax amount included in the payment, using the common monetary amount schema.

paymentInstrument

Parameter	Type	Required	Description
`paymentMethodName`	String	Required	Set to `ByBitPay`.
`incomingDetails`	Object	Required	Bybit Pay details listed below.

incomingDetails

Full path: payments[].paymentInstrument.incomingDetails.

Parameter	Type	Required	Description
`sessionTimeoutMin`	Integer	Optional	Payment session lifetime in minutes.
`redirectUrl`	String	Required	URL to return the payer to after a successful payment.
`failureUrl`	String	Required	URL to return the payer to after a failed payment.
`terminalType`	String	Required	Transaction source: `APP`, `WEB`, `WAP`, `MINIAPP`, or `OTHERS`.
`device`	String	Required	Identifier of the payer's device.
`browserVersion`	String	Required	Browser or application version information for the payer's environment.
`ip`	String	Required	Payer IP address.

submittedAmount

Parameter	Type	Required	Description
`value`	Number	Required	Payment amount as a JSON number, for example `100.50`. Use a decimal point as the separator.
`currency`	String	Required	Submitted currency code. Use a currency enabled for your integration.

📓
Response specifics

The response contains the created Intent and its payments.

When QR creation succeeds, the payment is in AUTHORIZATION_REQUESTED and awaits the payer's action.

The QR image is returned in payments[].additionalData.details.qrBase64. Display this image on your checkout page.

Save payments[].id: use this platform payment identifier when requesting a refund.

Check paymentCreationErrors and each returned payment's status before displaying a QR. HTTP 200 alone does not confirm that every requested payment was created. An entry in paymentCreationErrors and a created payment with status = ERROR are separate response cases.

Intent Response: Example

The example shows the fields relevant to this flow. CURRENCY_CODE and BASE64_ENCODED_QR_IMAGE are placeholders; the latter represents the returned QR image data.

{
  "intentId": "344115072451633152",
  "payments": [
    {
      "id": "344115072812343296",
      "submittedAmount": {
        "value": 100.50,
        "currency": "USDT"
      },
      "authAmount": {
        "value": 100.50,
        "currency": "USDT"
      },
      "paymentInstrument": {
        "paymentMethodName": "ByBitPay"
      },
      "status": "AUTHORIZATION_REQUESTED",
      "additionalData": {
        "details": {
          "qrBase64": "BASE64_ENCODED_QR_IMAGE",
          "url": "bybit-payment-url"
        }
      }
    }
  ],
  "disbursements": [],
  "clientReferenceIntentId": "order-bybit-1001",
  "paymentCreationErrors": [],
  "disbursementCreationErrors": [],
  "intentStatus": "IN_PROGRESS"
}

Intent Response: Fields Description

Top-Level Response Parameters

Parameter	Type	Description
`intentId`	String	Intent identifier in our platform.
`payments`	Array of Objects	Created payments and their current statuses.
`disbursements`	Array	Empty in this payment-only example.
`clientReferenceIntentId`	String	Your intent reference, supplied as top-level `clientReferenceId` in the request.
`paymentCreationErrors`	Array	Payment creation errors, if any. Empty when there are no such errors.
`disbursementCreationErrors`	Array	Disbursement creation errors. Empty in this payment-only example.
`intentStatus`	String	Overall intent status. The example is `IN_PROGRESS` while the payment awaits completion.

payment — payments[]

Parameter	Type	Description
`id`	String	Platform payment identifier. Save this value for subsequent operations, including refunds.
`submittedAmount`	Object	Submitted payment amount and currency.
`authAmount`	Object	Authorisation amount and currency used for the payment.
`paymentInstrument`	Object	Payment method information.
`status`	String	Current payment status. `AUTHORIZATION_REQUESTED` means the payment awaits completion.
`additionalData`	Object	Method-specific data needed to continue the payment. Returned when applicable.

submittedAmount / authAmount

Parameter	Type	Description
`value`	Number	Amount in the corresponding currency.
`currency`	String	Currency of this amount. Submitted and authorisation currencies can differ if currency conversion applies.

paymentInstrument

Parameter	Type	Description
`paymentMethodName`	String	`ByBitPay` for this flow.
`id`	String	Payment instrument identifier, when returned.
`paymentMethodId`	String	Payment method identifier, when returned.
`storedDetails`	Object	Stored payment instrument details, when returned.

additionalData.details

Parameter	Type	Description
`qrBase64`	String	Payment QR image encoded as plain Base64, without a data URI prefix. Available when QR creation succeeds. Decode it as image data before displaying it; the string itself is not a payment URL. In the sandbox, it is a PNG whose QR encodes the emulator link in `url`.
`url`	String	In the sandbox response, the emulator URL for completing the test payment. Open the complete returned URL without modifying it. See Testing in Sandbox for the response example and trigger behaviour.

Payment Statuses

Status	Meaning
`AUTHORIZATION_REQUESTED`	The payment has been initiated and awaits completion. In the successful QR creation flow, the QR is available for display.
`CAPTURED`	Payment completed successfully. Final payment status.
`DECLINED`	Payment was declined. Final payment status. See the sandbox scenario for a simulated decline.
`CANCELLED`	The payment session expired before completion. Final payment status for the expiration scenario.
`ERROR`	Payment processing failed. In the `LinkCreationError` sandbox scenario, this status is returned synchronously and no usable QR is created.

Webhooks

Our platform sends transaction status updates using the following URL selection:

The webhookUrl supplied for the payment or refund.
If that field is omitted, the default webhook URL configured for the settlement account.

If neither URL is configured, no webhook is sent. A refund's URL is resolved independently of the original payment's URL.

Webhooks use HTTPS POST requests with a JSON body. Acknowledge receipt with an HTTP 2xx response. See Webhooks: Overview for delivery rules and Webhooks: Example for payloads.

Transaction	Optional URL override	Outcomes described on this page
Payment	`payments[].webhookUrl` in the intent creation request	`CAPTURED`, `DECLINED`, `CANCELLED`, or a processing `ERROR`.
Refund	`webhookUrl` in the refund creation request	`REFUNDED`, `DECLINED`, or a technical `ERROR`.

Use the transaction identifier and status in the webhook to update your records. Payment and refund statuses belong to their respective transactions. The table lists the outcomes covered here; it is not an exhaustive list of notifications. Handle intermediate updates according to the common webhook contract.

If you do not receive a result notification, retrieve the current payment or refund by its platform ID. A missing webhook does not establish whether an operation succeeded or failed.

Workflow: Refunds

Create a refund for an existing Bybit Pay payment in CAPTURED status. The request references the original platform payment ID returned as payments[].id.

The diagram shows a request accepted for processing. Request validation failures are returned synchronously; see Refund Creation Errors below.

How It Works

Step	What happens
1	The payer asks you for a refund.
2	You send a refund creation request with the original `paymentId`.
3	Our platform validates the request and creates a separate `Refund` transaction.
4	A successful HTTP `200` response with `status = ACCEPTED` confirms acceptance for processing.
5	Our platform submits the refund request to Bybit.
6	Bybit returns the refund result.
7	Our platform records the refund result: `REFUNDED` or `DECLINED`. Technical processing failures can result in `ERROR`.
8	Our platform sends the latest refund status to the configured webhook URL, if available.

Refund Request/Response

📓
Request specifics

Endpoint: POST /processing/api/v1/refunds.

Original transaction: a payment in CAPTURED status.

Example below: a full refund. Omit paymentSubmittedAmount and paymentAuthAmount to request the original payment amounts.

Existing successful or in-progress refunds reduce the amount available for refund. Omitting the amount fields requests the original amount, not just the remaining balance; the request must pass the available-amount checks.

Full Refund Request: Example

{
  "paymentId": 344115072812343296,
  "reason": "Customer requested a refund",
  "clientReferenceId": "order-bybit-1001-refund-1",
  "webhookUrl": "https://merchant.example.com/webhooks/refunds"
}

Full Refund Request: Fields Description

Parameter	Type	Required	Description
`paymentId`	Integer (int64)	Required	Original platform payment identifier. Use the exact value of `payments[].id` from the intent creation response.
`partial`	Boolean	Optional	Defaults to `false`. Omit it or set it to `false` for the full refund example.
`reason`	String	Optional	Reason for the refund.
`clientReferenceId`	String	Optional	Your reference for one logical refund, unique within the settlement account. If supplied, it must be non-empty and no longer than 2048 characters. Preserve the same value when retrying that refund.
`webhookUrl`	String	Optional	HTTPS endpoint for this refund's status updates. Overrides the settlement account's default webhook URL. If omitted, the account default is used. Configure either URL to receive notifications.

paymentId is a JSON integer in the refund request, while it is returned as a string in responses. Preserve the identifier exactly: these int64 values can exceed the exact integer range of JavaScript Number.

📓
Response specifics
A successful HTTP 200 response with status = ACCEPTED confirms acceptance for processing. Treat the refund as completed only when its status is REFUNDED. Status updates are sent when a webhook URL is configured. You can also retrieve the current refund status.

Refund Response: Example

This example shows a full refund of the payment illustrated above. CURRENCY_CODE represents that payment's currency. Fields relevant to this flow are shown.

{
  "id": "344115098234117632",
  "intentId": "344115072451633152",
  "paymentId": "344115072812343296",
  "refundSubmittedAmount": {
    "value": 100.50,
    "currency": "CURRENCY_CODE"
  },
  "refundAuthAmount": {
    "value": 100.50,
    "currency": "CURRENCY_CODE"
  },
  "reason": "Customer requested a refund",
  "status": "ACCEPTED",
  "createdAt": "2026-09-15T10:15:12.318Z",
  "clientReferenceTransactionId": "order-bybit-1001-refund-1"
}

Refund Response: Fields Description

Parameter	Type	Description
`id`	String	Platform refund identifier. Save it to identify this refund.
`intentId`	String	Identifier of the intent containing the original payment.
`paymentId`	String	Identifier of the original payment.
`refundSubmittedAmount`	Object	Refund amount and currency in submitted terms. Contains numeric `value` and string `currency`.
`refundAuthAmount`	Object	Refund amount and currency in authorisation terms. Contains numeric `value` and string `currency`.
`reason`	String	Reason supplied in the request, when present.
`status`	String	Current refund status. The acceptance response is `ACCEPTED`.
`createdAt`	String	Refund creation time in ISO 8601 format.
`clientReferenceTransactionId`	String	Your refund reference supplied as `clientReferenceId`, when present.

Refund Statuses

Status	Meaning
`ACCEPTED`	The platform accepted the refund request for processing.
`REFUND_REQUESTED`	Refund processing has been requested; a final result is pending.
`REFUNDED`	The refund completed successfully. Final refund status.
`DECLINED`	The refund was declined. Final refund status.
`ERROR`	A technical error occurred while processing the refund. Final refund status in the platform.

Refund Creation Errors

A failed creation request does not have the successful response shown above. The common error response uses errorCode, failureMessage, and timestamp; see the Refund API reference for the schema.

HTTP status	Meaning
`400`	Invalid refund request or refund creation failure.
`404`	The original payment was not found or is unavailable to the caller.
`409`	A duplicate refund reference or a conflict with another refund creation operation.

Retrying a Refund Request

Use one clientReferenceId per logical refund. If the HTTP response is lost or times out, preserve that reference when retrying the same refund. A refund already created with the same reference is rejected with HTTP 409; the original successful response is not replayed.

Check the existing refund before submitting a new logical refund. When its platform ID is known, use GET /processing/api/v1/refunds/{id}. A timeout or 409 alone does not establish the final refund result.

Testing in Sandbox

Use the Bybit Pay emulator to test your handling of QR creation, successful payments, declines, and expiration.

Set payments[].paymentInstrument.paymentMethodName to ByBitPay and provide the required incoming details as in the production request.

For the webhook-based tests below, provide payments[].webhookUrl or configure a default webhook URL for the settlement account.

Select a scenario through the top-level description in the intent creation request, referred to below as intent.description. For a scenario without a keyword, omit this field or send an empty string.

Bybit Pay Payment Test Flow

📘
The sandbox response returns the test payment link in payments[].additionalData.details.url. The QR in payments[].additionalData.details.qrBase64 encodes the same link.
Opening the URL triggers the scenario result. Open it directly, or scan the QR with a QR reader and open the decoded link. The sandbox QR opens the platform's emulator. Displaying the QR image alone does not complete the payment.
For the expiration scenario, leave the test link unopened and wait for the payment session to expire.

Sandbox Response: Relevant Fields

The following is the additionalData fragment of a sandbox payment returned with status = AUTHORIZATION_REQUESTED. SANDBOX_PAYMENT_URL and BASE64_ENCODED_PNG_QR_IMAGE are placeholders for values returned by the API.

{
  "details": {
    "url": "SANDBOX_PAYMENT_URL",
    "qrBase64": "BASE64_ENCODED_PNG_QR_IMAGE"
  }
}

Field	Format	How to use
`payments[].additionalData.details.url`	String containing the complete emulator URL.	Open the returned value as-is to trigger the selected scenario. Do not construct the URL or change its query parameters.
`payments[].additionalData.details.qrBase64`	PNG image encoded as plain Base64, without a data URI prefix.	Display the image. Scanning it yields the same URL as `details.url`. Opening that URL triggers the selected scenario.

Displaying the Sandbox QR in a Browser

For a returned payment object named payment and an HTML image element named qrImage:

qrImage.src =

This displays the image only. Open payment.additionalData.details.url separately when you are ready to simulate the successful or declined payment.

List of Supported Cases

Case	Scenario keyword (`intent.description`)	Action	Expected payment status
Successful payment	No keyword	Open `payments[].additionalData.details.url` before expiration.	`AUTHORIZATION_REQUESTED` → `CAPTURED`
QR expired	No keyword	Leave the link unopened and wait for expiration.	`AUTHORIZATION_REQUESTED` → `CANCELLED`
Payment declined	`DeclinedPayment`	Open `payments[].additionalData.details.url` before expiration.	`AUTHORIZATION_REQUESTED` → `DECLINED`
QR creation error	`LinkCreationError`	Send the intent creation request.	`ERROR` in the synchronous response.

Successful Payment

Create an intent using the request template above, with no scenario keyword in the top-level description.
Check that the response contains a payment in AUTHORIZATION_REQUESTED and a QR in payments[].additionalData.details.qrBase64.
Display the QR on your checkout page and open payments[].additionalData.details.url before the session expires.
Receive the payment status webhook and check that the payment status is CAPTURED.

Bybit Pay - Payments

Payment Method Name

Payment Method Features

Workflow: Payment

Possible Payment Scenarios

List of Used API Requests

Intent Creation Request/Response

Request specifics

Intent Request: Template

Intent Request: Fields Description

Response specifics

Intent Response: Example

Intent Response: Fields Description

Payment Statuses

Webhooks

Workflow: Refunds

How It Works

Refund Request/Response

Request specifics

Full Refund Request: Example

Full Refund Request: Fields Description

Response specifics

Refund Response: Example

Refund Response: Fields Description

Refund Statuses

Refund Creation Errors

Retrying a Refund Request

Testing in Sandbox

Bybit Pay Payment Test Flow

Sandbox Response: Relevant Fields

Displaying the Sandbox QR in a Browser

List of Supported Cases

Successful Payment

QR Expiration

Declined Payment

QR Creation Error
